Background And Identification

The HP Pavilion 14-cf0014dx is a 14 inch laptop part of the HP lineup. It was released on June 30th, 2018 and has Windows 10 installed on it by default. It has a core i3 processor, 8 GB of RAM, Intel HD Graphics 620 and a 128 GB hard drive. It also includes a 14 inch screen with a silver exterior. On the side, it has three USB ports and an HDMI port next to a headphone slot.

Specification

Product Number: 5BM69UA

Product Name: HP Notebook - 14-cf0014dx

Microprocessor: Intel® Core™ i3-7100U

Memory: 8 GB DDR4-2133 SDRAM

Video Graphics: Intel® HD Graphics 620

Hard Drive: 128 GB M.2 SSD

Display: 14" diagonal HD SVA BrightView micro-edge WLED-backlit

Expansion Slots: 1 multi-format SD media card reader

External Ports: 1 USB 3.1 Type-C™ Gen 1; 2 USB 3.1 Gen 1 ; 1 HDMI 1.4b. 1 RJ-45; 1 headphone/microphone combo

Dimensions: 32.4 x 22.59 x 1.99 cm

Weight: 1.43 kg

Power Supply Type: 45 W Smart AC adapter

Battery Type: 3-cell, 41 Wh Li-ion

Audio feature: Dual speakers
