How can make ListView control to scroll to show the hidden items and toolbar always show when I add the listview item?

Question

The following code show the UI a1.png that I hoped, but there are some problems with the code, the bottom toolbar buttons will not show when I add some listview items just like 2.png.

I hope that the bottom toolbar button always show, and ListView control can acroll to show the hidden items when I add some listview items.

BTW, I hope btnAddNumber button near the ListView control, and the position of btnAddNumber will be move down when add the listview item, and btnAddNumber maybe hide when I add many listview items, but I can scroll screen to make it show.

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:ads="http://schemas.android.com/apk/lib/com.google.ads"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
    android:background="@drawable/border_ui"
    android:orientation="vertical" >

    <com.google.ads.AdView
        android:id="@+id/adView"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        ads:adSize="SMART_BANNER"
        ads:adUnitId="aaaaa"
        ads:loadAdOnCreate="false" />

    <ListView
        android:id="@android:id/list"
        android:layout_width="fill_parent"
        android:layout_height="wrap_content"
        android:background="#FFFFFF"
        android:textSize="16sp" />

     <LinearLayout
            android:layout_width="fill_parent"
            android:layout_height="wrap_content"
            android:layout_gravity="top"
            android:gravity="center"
            android:orientation="horizontal" >

        <Button
            android:id="@+id/btnAddNumber"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:text="Add Number" />
    </LinearLayout>

    <TextView
        android:id="@+id/tvOnlyFullSpace"
        android:layout_width="wrap_content"
        android:layout_height="0dip"
        android:layout_weight="1"
        android:text="" />

    <LinearLayout
        android:layout_width="fill_parent"
        android:layout_height="wrap_content"
        android:layout_gravity="center_vertical"
        android:background="#DCDCDC"
        android:gravity="center"
        android:orientation="horizontal" >

       <Button
            android:id="@+id/btnBack"
            style="@style/myTextAppearance"
            android:layout_width="0dip"
            android:layout_height="fill_parent"
            android:layout_weight="1"
            android:text="Back" />


        <Button
            android:id="@+id/btnNext"
            style="@style/myTextAppearance"
            android:layout_width="0dip"
            android:layout_height="fill_parent"
            android:layout_weight="1"
            android:text="Next" />

        <Button
            android:id="@+id/btnCancel"
            style="@style/myTextAppearance"
            android:layout_width="0dip"
            android:layout_height="fill_parent"
            android:layout_weight="1"
            android:text="Cancel" />

    </LinearLayout>

</LinearLayout>

enter image description here

enter image description here

Thanks! Could you tell me how to add the buttons as a footer to listview — HelloCW, Nov 19 '13 at 15:32
the tool bar will not show always. use a relative layout fix the tool bar to the bottom. relative to toolbar add the listview above it — Raghunandan, Nov 19 '13 at 15:35

score 1 · Accepted Answer · edited May 23 '17 at 12:12

You can use a RelativeLayout

  <RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent" >

    <View
        android:id="@+id/adView"
        android:layout_width="wrap_content"
        android:layout_height="50dp"
        android:layout_alignParentTop="true"

      />
    <LinearLayout
        android:id="@+id/linearLayout1"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_alignParentBottom="true"
        android:layout_centerHorizontal="true"
        android:orientation="horizontal" >

        <Button
            android:id="@+id/btnBack"
            android:layout_width="0dp"
            android:layout_height="fill_parent"
            android:layout_weight="1"
            android:text="Back" />

        <Button
            android:id="@+id/btnNext"
            android:layout_width="0dp"
            android:layout_height="fill_parent"
            android:layout_weight="1"
            android:text="Next" />

        <Button
            android:id="@+id/btnCancel"
            android:layout_width="0dp"
            android:layout_height="fill_parent"
            android:layout_weight="1"
            android:text="Cancel" />
    </LinearLayout>

    <ListView
        android:id="@+id/listView1"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_below="@+id/adView"
        android:layout_above="@+id/btnAddNumber"
        android:layout_alignParentLeft="true" >

    </ListView>

        <Button
            android:id="@+id/btnAddNumber"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:layout_above="@+id/linearLayout1"
            android:layout_centerHorizontal="true"
            android:text="Add Number" />

</RelativeLayout>

snap

Now the 3 buttons are fixed at the bottom (always) of the screen. Above which you have another Add Number above which you have listview.

There is some space above listview for the view ( in your case adView);

enter image description here

Edit:

You can also add buttons as a footer to listview.

How to add a footer in ListView?
