How do I populate two sections in a tableview with two different arrays using swift?

Question

I have two arrays Data1 and Data2 and I want to populate the data within each of these (they contain strings) into a tableview in two different sections.

The first section should have a heading "Some Data 1" and the second section should be titled "KickAss".

I have both sections populating with data from the first array (but with no headings either).

Here is my code so far:

override func numberOfSectionsInTableView(tableView: UITableView) -> Int {
    return 2
}

override func tableView(tableView: UITableView, numberOfRowsInSection section: Int) -> Int {
    var rowCount = 0
    if section == 0 {
        rowCount = Data1.count
    }
    if section == 1 {
        rowCount = Data2.count
    }
    return rowCount
}

override func tableView(tableView: UITableView, cellForRowAtIndexPath indexPath: NSIndexPath) -> UITableViewCell {
    let cell = tableView.dequeueReusableCellWithIdentifier("Cell", forIndexPath: indexPath) as UITableViewCell
    let ip = indexPath
    cell.textLabel?.text = Data1[ip.row] as String
    return cell
}

in the cellForRowAtIndexPath method, is it possible for me to identify the section somehow like I did in the numberOfRowsInSection method?

Also, how do I give titles to each section?

I have been searching for this for a couple hours and this is the only thing that worked for me. Thanks so much. — A.J. Hernandez, Jul 06 '16 at 22:34

ABakerSmith · Accepted Answer · 2015-04-11T14:41:43.150

TableView Cells

You could use a multidimensional array. For example:

let data = [["0,0", "0,1", "0,2"], ["1,0", "1,1", "1,2"]]

For the number of sections use:

override func numberOfSectionsInTableView(tableView: UITableView) -> Int {
    return data.count
}

Then, to specify the number of rows in each section use:

override func tableView(tableView: UITableView, numberOfRowsInSection section: Int) -> Int {
    return data[section].count
}

Finally, you need to setup your cells:

override func tableView(tableView: UITableView, cellForRowAtIndexPath indexPath: NSIndexPath) -> UITableViewCell {
    let cellText = data[indexPath.section][indexPath.row]

    //  Now do whatever you were going to do with the title.
}

TableView Headers

You could again use an array, but with just one dimension this time:

let headerTitles = ["Some Data 1", "KickAss"]

Now to set the titles for the sections:

override func tableView(tableView: UITableView, titleForHeaderInSection section: Int) -> String? {
    if section < headerTitles.count {
        return headerTitles[section]
    }

    return nil
}

The code above checks to see there's a title for that section and returns it, otherwise nil is returned. There won't be a title if the number of titles in headerTitles is smaller than the number of arrays in data.

The Result

enter image description here

I try to use this but cannot work, could you help me here? https://stackoverflow.com/questions/61587806/how-to-move-rows-in-uitableview-changing-even-the-section — biggreentree, May 04 '20 at 08:15

score 31 · Answer 2 · answered Apr 11 '15 at 15:03

You could create a Struct to hold the data that belongs to a section, as an alternative to my previous answer. For example:

struct SectionData {
    let title: String
    let data : [String]

    var numberOfItems: Int {
        return data.count
    }

    subscript(index: Int) -> String {
        return data[index]
    }
}

extension SectionData {
    //  Putting a new init method here means we can
    //  keep the original, memberwise initaliser.
    init(title: String, data: String...) {
        self.title = title
        self.data  = data
    }
}

Now in your view controller you could setup your section data like so:

lazy var mySections: [SectionData] = {
    let section1 = SectionData(title: "Some Data 1", data: "0, 1", "0, 2", "0, 3")
    let section2 = SectionData(title: "KickAss", data: "1, 0", "1, 1", "1, 2")

    return [section1, section2]
}()

Section Headers

override func numberOfSectionsInTableView(tableView: UITableView) -> Int {
    return mySections.count
}

override func tableView(tableView: UITableView, titleForHeaderInSection section: Int) -> String? {
    return mySections[section].title
}

Compared to my previous answer, you now don't have to worry about matching the number of headerTitles to the number of arrays in data.

TableView Cells

override func tableView(tableView: UITableView, numberOfRowsInSection section: Int) -> Int {
    return mySections[section].numberOfItems
}

override func tableView(tableView: UITableView, cellForRowAtIndexPath indexPath: NSIndexPath) -> UITableViewCell {
    let cellTitle = mySections[indexPath.section][indexPath.row]

    let cell = tableView.dequeueReusableCellWithIdentifier("Cell", forIndexPath: indexPath) as! UITableViewCell
    cell.textLabel?.text = cellTitle

    return cell
}

I followed this steps (iOS10, Swift 3) and it works. Quite helpful. Thanks! — Kaihua, Nov 16 '16 at 01:02
Great solution! Much better to use structs than 2D arrays in this case — Imran, Mar 17 '17 at 05:20
How can apply this solution to the same build up but with dynamic cells? I have 4 different arrays which populate two sections controlled by a segmented control with two segments. The problem I am facing with you solution is that my sections has noch subscript members which is way I cannot fill the cells. — AlexVilla147, Jun 26 '17 at 20:07
Great solution, Just a quick note. The `init()` cannot be in an extension. It would give you a `redeclaration` error. Moving the `init()` to the struct body itself solves this issue. — Anjan Biswas, Nov 07 '17 at 23:04
lazy var mySections: [SectionData] ? declaration? so Need to access in other function — kiran, Aug 03 '21 at 20:54

score 14 · Answer 3 · answered Apr 11 '15 at 14:30

14

You can determine which section you are in by looking at indexPath.section. To specify the titles, override the function

func tableView(tableView: UITableView!, titleForHeaderInSection section: Int) -> String!

answered Apr 11 '15 at 14:30

Glorfindel

21,988
13
81
109

Thank you all. This was the quick and dirty solution I went with. – Woody Apr 11 '15 at 16:59

score 1 · Answer 4 · edited Dec 07 '19 at 01:33

In Swift 4 or Swift 5 you can use the code below.

Here a custom header section with filter is shown:

create a project
Add table view
create UITableView Cell
Connect label to uitable view & table with view controller

Add bellow code

import UIKit

struct Category {
let name : String
var items : [[String:Any]]
}

 class ViewController: UIViewController,UITableViewDelegate,UITableViewDataSource,UITextFieldDelegate {
  @IBOutlet weak var txtName: UITextField!

 @IBOutlet weak var tableView: UITableView!

var originalArr = [[String:Any]]();
var recentArr = [[String:Any]]();
var searchArrRes = [[String:Any]]()
var searching:Bool = false

 //
var sections = [Category]()

override func viewDidLoad() {
  super.viewDidLoad()

//Assign delegate  don't forget
txtName.delegate = self
tableView.delegate = self
tableView.dataSource = self



recentArr =   [
    ["name": "Enamul", "number": "+8800000003"],
    ["name": "Enam", "number": "+8800000004"]
]

originalArr = [
    ["name": "abdul", "number": "+8800000001"],
    ["name": "abdin", "number": "+8800000002"],
    ["name": "Enamul", "number": "+8800000003"],
    ["name": "enam", "number": "+8800000004"],
    ["name": "Rafi", "number": "+8800000005"],
    ["name": "Ehaque", "number": "+8800000006"]
   ]

 //my array
  sections = [
      Category(name:"Recent", items:recentArr),
      Category(name:"ALL", items:originalArr)
      ]

      }


   func textFieldShouldReturn(_ textField: UITextField) -> Bool {
    textField.resignFirstResponder()
    return true
     }

 func tableView(_ tableView: UITableView, willDisplayHeaderView view: UIView, forSection section: Int) {
      guard let tableView = view as? UITableViewHeaderFooterView else { return }

   tableView.textLabel?.textColor = UIColor.red
 }

 public func textField(_ textField: UITextField, shouldChangeCharactersIn range: NSRange, replacementString string: String) -> Bool{
//input text
let searchText  = textField.text! + string

searchArrRes = self.originalArr.filter({(($0["name"] as! String).localizedCaseInsensitiveContains(searchText))})


if(searchArrRes.count == 0){
    searching = false
}else{
    searching = true
}
self.tableView.reloadData();

return true
}


  func numberOfSections(in tableView: UITableView) -> Int {
if( searching == true){
    return 1
    }
   return self.sections.count
   }

  func tableView(_ tableView: UITableView, titleForHeaderInSection section: Int) -> String? {
if( searching == true){
    return ""
   }
  return self.sections[section].name
  }

   func tableView(_ tableView: UITableView, numberOfRowsInSection section: Int) -> Int {
if( searching == true){
   return searchArrRes.count
}else{
    let items = self.sections[section].items
    return items.count
  }
 }

 func tableView(_ tableView: UITableView, cellForRowAt indexPath: IndexPath) -> UITableViewCell {
   let cell = tableView.dequeueReusableCell(withIdentifier: "cell", for: indexPath) as! Custom_cell
  //  var dict = itemsA[indexPath.section]

if( searching == true){
    var dict = searchArrRes[indexPath.row]
    cell.name.text = dict["name"] as? String
    cell.number.text = dict["number"] as? String
 }else{
    let items = self.sections[indexPath.section].items
    let item = items[indexPath.row]
    cell.name.text = item["name"] as? String
    cell.number.text = item["number"] as? String

    }

    return cell
     }


}

You can download full source from GitHub.GitHub Like: https://github.com/enamul95/Custom_table_view_section.git

score 0 · Answer 5 · answered Mar 09 '20 at 10:45

Can do Sections in Tableview and can change the colours of Header sections

   class ViewController: UIViewController, UITableViewDelegate, UITableViewDataSource {

@IBOutlet weak var tabview: UITableView!

var tablecell = NewTableViewCell()

let data = [["SWIFT", "BALENO", "ALTO", "CIAZ"], ["INNOVA", "GLANZA", "FORTUNER"] , ["BMW X5", "BMW M4", "BMW 7 Series", "BMW X7", "BMW i3"]]

let brand: Array<String> = ["MARUTHI", "TOYOTA", "BMW"]



override func viewDidLoad() {
    super.viewDidLoad()

}


 func numberOfSections(in tableView: UITableView) -> Int {
    return brand.count
}

  func tableView(_ tableView: UITableView, numberOfRowsInSection section: Int) -> Int {
       return data[section].count    }


func tableView(_ tableView: UITableView, titleForHeaderInSection section: Int) -> String? {

    return self.brand[section]

}


func tableView(_ tableView: UITableView, willDisplayHeaderView view: UIView, forSection section: Int) {

    // can change the header color of background and title with this code :)

    (view as! UITableViewHeaderFooterView).contentView.backgroundColor = UIColor.red.withAlphaComponent(0.4)
    (view as! UITableViewHeaderFooterView).textLabel?.textColor = UIColor.yellow

    }



func tableView(_ tableView: UITableView, cellForRowAt indexPath: IndexPath) -> UITableViewCell {

    let cell1: NewTableViewCell = tableView.dequeueReusableCell(withIdentifier: "cell1") as! NewTableViewCell

    let text = data[indexPath.section][indexPath.row]

    cell1.textLabel!.text = text

    return cell1
}




override func didReceiveMemoryWarning() {
    super.didReceiveMemoryWarning()
    // Dispose of any resources that can be recreated.
}


}
