How to get the time elapsed time after using the reset of the "Elapsed Time" component?

Question

I am calculating the capacitance of a circuit using LabVieW. I have tried to get the time after the voltage across it reaches 2.5V. I am giving a supply of 5V. I used a logic operator and connected it to the reset to the elapsed time component. But I get zero as the time gets reseted. I want to get the actual time elapsed.

The block diagram of the circuit:

I believe Elapsed Time is meant to be used more like a timer than a stopwatch--the focus being on comparing a timing constant to a running timer and letting you know when they match. Instead consider getting a timestamp at the start and another timestamp when the voltage reaches 2.5V, then get the difference. — Dave_St, Aug 20 '18 at 14:25

score 1 · Accepted Answer · edited Aug 22 '18 at 06:25

1

Try this code: Do not wire something on the reset and place a False on the Auto Reset Input

Block Diagram

edited Aug 22 '18 at 06:25

Roy Scheffers

3,832
11
31
36

answered Aug 22 '18 at 05:01

Edrick

26
5
