How to remove top status bar black background

Question

I'd like to create a TRUE fullscreen activity, but there is always a black status bar on screen top. Android 9.0.

I've tried almost all I can find with Google and existing Apps with similar jobs. Manifest, code, style, AS sample fullscreen activity, all were tried.

styles.xml:

    <style name="AppThemeA" parent="@style/Theme.AppCompat.Light.NoActionBar">
        <item name="android:statusBarColor">@android:color/transparent</item>
        <item name="android:windowNoTitle">true</item>
        <item name="android:windowActionBar">false</item>
        <item name="android:windowFullscreen">true</item>
        <item name="android:windowContentOverlay">@null</item>
        <item name="android:windowTranslucentStatus">true</item>
        <item name="android:windowTranslucentNavigation">true</item>
    </style>

Manifest:

<activity android:name=".ScreenActivity" android:theme="@style/AppThemeA" />

Layout:

<?xml version="1.0" encoding="utf-8"?>
<androidx.coordinatorlayout.widget.CoordinatorLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <FrameLayout
        android:id="@+id/rootLayout"
        android:fitsSystemWindows="true"
        android:layout_width="match_parent"
        android:layout_height="match_parent" />

</androidx.coordinatorlayout.widget.CoordinatorLayout>

Kotlin (commented lines are tried and failed):

class ScreenActivity : AppCompatActivity() {
    override fun onCreate(savedInstanceState: Bundle?) {
        //setTheme(R.style.AppThemeDetector)
        super.onCreate(savedInstanceState)


        //window.setFlags(WindowManager.LayoutParams.FLAG_FULLSCREEN, WindowManager.LayoutParams.FLAG_FULLSCREEN)
        //window.setFlags(WindowManager.LayoutParams.FLAG_LAYOUT_NO_LIMITS, WindowManager.LayoutParams.FLAG_LAYOUT_NO_LIMITS)
        //window.decorView.systemUiVisibility = View.SYSTEM_UI_FLAG_LIGHT_STATUS_BAR or View.SYSTEM_UI_FLAG_HIDE_NAVIGATION or View.SYSTEM_UI_FLAG_IMMERSIVE_STICKY or View.SYSTEM_UI_FLAG_FULLSCREEN

        /*
        window.decorView.systemUiVisibility = (
                View.SYSTEM_UI_FLAG_LAYOUT_HIDE_NAVIGATION
                        or View.SYSTEM_UI_FLAG_LAYOUT_STABLE
                        or View.SYSTEM_UI_FLAG_LAYOUT_FULLSCREEN
                        or View.SYSTEM_UI_FLAG_FULLSCREEN
                )*/

        setContentView(R.layout.activity_screen_detector)
        ...
    }
}

The expected result:

What I actually got:

[[[[ Solution ]]]]

Found what caused this. You should set the App to FullScreen App in Settings -> Display.

https://www.gottabemobile.com/how-to-enable-full-screen-apps-on-galaxy-s10

So fixed. Thanks for all your help.

You can comment on each individual answer to say if it did not work, rather than updating the question. — Gino Mempin, May 29 '19 at 05:51
Try this: https://stackoverflow.com/questions/26492522/how-do-i-remove-the-title-bar-in-android-studio/53792380#53792380 — ShehrozEK, May 29 '19 at 05:54
try this:https://stackoverflow.com/questions/39341818/how-to-change-the-color-of-the-status-bar-in-android/39341866 — Sanjeev S, May 29 '19 at 06:11
try this [Link](https://stackoverflow.com/questions/29311078/android-completely-transparent-status-bar) It will help you lot. — BlackBlind, Feb 17 '20 at 09:52

fullmoon · Answer 1 · 2020-04-24T10:47:00.217

I had a problem with displaying content through the notch or the cutout area. Found this in the docs:

LAYOUT_IN_DISPLAY_CUTOUT_MODE_SHORT_EDGES - Content renders into the cutout area in both portrait and landscape modes.

Key thing for me was this line in the activity style:

// Important to draw through the cutouts
<item name="android:windowLayoutInDisplayCutoutMode">shortEdges</item>

I wanted to show an image in immersive mode, and when I click it, the system UI (status & navigation bars) should show up.

Here is my complete solution:

1- Methods to show/hide system UI in the Activity

private fun hideSystemUI() {
    sysUIHidden = true
    window.decorView.systemUiVisibility = (
            View.SYSTEM_UI_FLAG_IMMERSIVE_STICKY
            or View.SYSTEM_UI_FLAG_LAYOUT_STABLE
            // Hide the nav bar and status bar
            or View.SYSTEM_UI_FLAG_HIDE_NAVIGATION // Hide nav bar
            or View.SYSTEM_UI_FLAG_FULLSCREEN // Hide status bar
            )
}


private fun showSystemUI() {
    sysUIHidden = false
    window.decorView.systemUiVisibility = (
            View.SYSTEM_UI_FLAG_LAYOUT_STABLE
            // Set the content to appear under the system bars so that the
            // content doesn't resize when the system bars hide and show.
            or View.SYSTEM_UI_FLAG_LAYOUT_HIDE_NAVIGATION // layout Behind nav bar
            or View.SYSTEM_UI_FLAG_LAYOUT_FULLSCREEN // layout Behind status bar
            )
}

2- Make sure this in the root view of your xml layout

android:fitsSystemWindows="false"

3- The Style for the Full screen Activity will give status/navigation bars a semi transparent background when they show up:

<style name="FullscreenTheme" parent="AppTheme">
    <item name="android:actionBarStyle">@style/FullscreenActionBarStyle</item>
    <item name="android:windowActionBarOverlay">true</item>
    <item name="android:windowBackground">@null</item>
    <item name="metaButtonBarStyle">?android:attr/buttonBarStyle</item>
    <item name="metaButtonBarButtonStyle">?android:attr/buttonBarButtonStyle</item>
    <item name="android:statusBarColor">#50000000</item>
    <item name="android:navigationBarColor">#50000000</item>
    // Important to draw behind cutouts
    <item name="android:windowLayoutInDisplayCutoutMode">shortEdges</item>
</style>

<style name="FullscreenActionBarStyle" parent="Widget.AppCompat.ActionBar">
    <item name="android:background">@color/sysTransparent</item>
</style>

score 15 · Answer 2 · answered Feb 17 '20 at 09:40

15

Add this method in your activity

public static void hideSystemUI() {
    getWindow().getDecorView().setSystemUiVisibility(
            View.SYSTEM_UI_FLAG_FULLSCREEN
                    | View.SYSTEM_UI_FLAG_LOW_PROFILE
                    | View.SYSTEM_UI_FLAG_LAYOUT_STABLE
                    | View.SYSTEM_UI_FLAG_IMMERSIVE
                    | View.SYSTEM_UI_FLAG_LAYOUT_HIDE_NAVIGATION
                    | View.SYSTEM_UI_FLAG_HIDE_NAVIGATION);
}

before adding this call this below super.onCreate(savedInstanceState); onCreate

    hideSystemUI();
    if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.P) {
        getWindow().getAttributes().layoutInDisplayCutoutMode = WindowManager.LayoutParams.LAYOUT_IN_DISPLAY_CUTOUT_MODE_SHORT_EDGES;
    }

above attribute is use if your device have notch cutout for camera.

answered Feb 17 '20 at 09:40

Thoriya Prahalad

2,492
2
13
16

2

This should be the accepted answer. Nothing else worked for me. – Axes Grinds Feb 01 '21 at 02:48
This is so simple and working, Nothing else worked for me. – Asad Mehmood Sep 30 '21 at 10:42
Worked for me and this should be the accepted answer. – Nabeel Ahmed May 24 '22 at 12:04
This is deprecated, according to the docs you should use `WindowInsetsController`. More info here https://stackoverflow.com/q/62577645/4544940 – Andy Jul 19 '22 at 01:04

Anice Jahanjoo · Answer 3 · 2019-05-29T06:02:11.250

1

In addition to your code you just need adding this code before your setContentView in your activity

this.requestWindowFeature(Window.FEATURE_NO_TITLE);

edited May 29 '19 at 06:02

answered May 29 '19 at 05:45

Anice Jahanjoo

7,088
3
20
29

Kochez · Answer 4 · 2022-06-28T11:28:03.170

So thanks to this video I got the solution.

First of all app theme should extend a NoActionBar Theme

<style name="Theme.YourApp" parent="Theme.MaterialComponents.DayNight.NoActionBar"></style>

There after in the Activity onCreate Method (In this case using viewBinding) should implemented as follows.

private lateinit var binding : ActivityMainBinding

override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)

    requestWindowFeature(Window.FEATURE_NO_TITLE)

    if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.P) {
        window.attributes.layoutInDisplayCutoutMode = WindowManager
              .LayoutParams
              .LAYOUT_IN_DISPLAY_CUTOUT_MODE_SHORT_EDGES
    }

    WindowCompat.setDecorFitsSystemWindows(window, false)

    binding = ActivityMainBinding.inflate(layoutInflater)

    WindowInsetsControllerCompat(window, binding.root).let { controller ->

        controller.hide(WindowInsetsCompat.Type.systemBars())
        controller.systemBarsBehavior = WindowInsetsControllerCompat
            .BEHAVIOR_SHOW_TRANSIENT_BARS_BY_SWIPE

    }

    setContentView(binding.root)

}

This worked for me. Hope it does for you as well.

score 0 · Answer 5 · answered May 29 '19 at 05:47

Here's a way to implement the edge-to-edge display starting from Android Q. The code is inspired by this blog.

First, in your styles.xml, modify the AppTheme like:

<style name="AppTheme" parent="Theme.MaterialComponents.Light.NoActionBar">
        ...
    <item name="android:navigationBarColor">@android:color/transparent</item>
    <item name="android:statusBarColor">@android:color/transparent</item>
</style>

Suppose, we need to make the MainActivity fullscreen, then in MainActivity.kt:

window.decorView.systemUiVisibility = (
                View.SYSTEM_UI_FLAG_LAYOUT_HIDE_NAVIGATION
                        or View.SYSTEM_UI_FLAG_LAYOUT_STABLE
                        or View.SYSTEM_UI_FLAG_LAYOUT_FULLSCREEN
                        or View.SYSTEM_UI_FLAG_FULLSCREEN
                )

Also, check the docs here for enabling fullscreen mode.

Tried, failed. Samsung S10+. – Shelley Shyan May 29 '19 at 05:55 — Shelley Shyan, May 29 '19 at 05:55
Which Android version you were using? – Shubham Panchal May 29 '19 at 07:44 — Shubham Panchal, May 29 '19 at 07:44
Samsung S10+, Android Pie – Shelley Shyan May 29 '19 at 08:53 — Shelley Shyan, May 29 '19 at 08:53

score 0 · Answer 6 · answered Jun 28 '22 at 11:39

First, in your styles.xml, modify the AppTheme like:

<style name="Theme.AppCompat.Light.NoActionBar.FullScreen" parent="@style/Theme.AppCompat.Light.NoActionBar">
    <item name="android:windowNoTitle">true</item>
    <item name="android:windowActionBar">false</item>
    <item name="android:windowFullscreen">true</item>
    <item name="android:windowContentOverlay">@null</item>
</style>

and also mention in your manifest file.

<activity
   android:name=".activities.FullViewActivity"
   android:theme="@style/Theme.AppCompat.Light.NoActionBar.FullScreen"
/>

score -1 · Answer 7 · answered May 29 '19 at 05:37

Try this:

if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.LOLLIPOP) {
    Window window = getWindow();
    window.addFlags(WindowManager.LayoutParams.FLAG_DRAWS_SYSTEM_BAR_BACKGROUNDS);
    window.setStatusBarColor(getResources().getColor(R.color.colorPrimary));
} else if (Build.VERSION.SDK_INT == Build.VERSION_CODES.KITKAT) {
    Window window = mContext.getWindow();
    window.setFlags(WindowManager.LayoutParams.FLAG_TRANSLUCENT_STATUS,
    WindowManager.LayoutParams.FLAG_TRANSLUCENT_STATUS);
    int statusBarHeight = (int) dpToPx(24);

    View view = new View(mContext);
    view.setLayoutParams(new FrameLayout.LayoutParams(ViewGroup.LayoutParams.MATCH_PARENT,
                ViewGroup.LayoutParams.WRAP_CONTENT));
    view.getLayoutParams().height = statusBarHeight;
    ((ViewGroup) window.getDecorView()).addView(view);
     view.setBackgroundColor(getResources().getColor(R.color.colorPrimary));
}

dpToPx

public float dpToPx(float dp) {
    return (dp * Resources.getSystem().getDisplayMetrics().density);
}

How to remove top status bar black background
