.Net Drawing gets ghost border and resizes in wrong position

Question

I'm facing an issue (ghost border) when an image is resized on the live server, but not on localhost. This is really weird. I did some research on web and found similar solutions:

1. https://mariusschulz.com/blog/preventing-ghost-borders-when-resizing-images-with-system-drawing
2. https://www.codeproject.com/Articles/11143/Image-Resizing-outperform-GDI
3. Ghost-borders ('ringing') when resizing in GDI+

Below is the code that I'm using, inside I have commented old code and new code.

protected byte[] ApplyResize(byte[] byteArray, int targetSize, Size originalSize = default(Size))
{
    using (MemoryStream ms = new MemoryStream(byteArray))
    {
        if (targetSize <= 0)
        {
            targetSize = 800;
        }

        var image = Image.FromStream(ms);
        var size = default(Size);
        if (originalSize != default(Size))
        {
            size = CalculateDimensions(originalSize, targetSize);
        }
        else
        {
            size = new Size(targetSize, targetSize);
        }

        var resized = new Bitmap(size.Width, size.Height);
        using (var graphics = Graphics.FromImage(resized))
        {
            //old code
            //graphics.CompositingQuality = CompositingQuality.HighSpeed;
            //graphics.InterpolationMode = InterpolationMode.HighQualityBicubic;
            //graphics.CompositingMode = CompositingMode.SourceCopy;
            //graphics.DrawImage(image, 0, 0, size.Width, size.Height);

            //new code
            graphics.CompositingQuality = CompositingQuality.HighSpeed;
            graphics.InterpolationMode = InterpolationMode.HighQualityBicubic;
            graphics.CompositingMode = CompositingMode.SourceCopy;
            var attributes = new ImageAttributes();
            attributes.SetWrapMode(WrapMode.TileFlipXY);
            var destination = new Rectangle(0, 0, size.Width, size.Height);
            graphics.DrawImage(image, destination, 0, 0, size.Width, size.Height, GraphicsUnit.Pixel, attributes);
        }
        using (var ms2 = new MemoryStream())
        {
            resized.Save(ms2, image.RawFormat);
            return ms2.ToArray();
        }
    }
}

I tested on the live server, yes, the ghost border is gone, but the image has gotten a wrong position.

This image is the expected result after resize, all clear, no problem

This is what happens on localhost and live server, when using the new code, image gets cut with weird position

Answer 1

To me it looks like the DPI (resolution) of the resized image is different than the real image. This would make sense, as the resolution of the new bitmap is dependent of the resolution of the display. And your server might not really have a display...

To make sure you get the expected results you should call setResolution on it with the resolution of the original image, right after creating the new image and before drawing to it, like this:

var resized = new Bitmap(size.Width, size.Height);
resized.SetResolution(image.HorizontalResolution, image.VerticalResolution);

This should be a good fix in general, as you might also get issues when running locally with image with have a different DPI than the one you are testing with.

On top of that, as was mentioned above, you should change the call to DrawImage to the following, as you forgot to specify the source rectangle:

graphics.DrawImage(image, destination, 0, 0, originalSize.Width, originalSize.Height, GraphicsUnit.Pixel, attributes);

Additionally you might need to explain what CalculateDimensions does, as this might produce something which is wrong and as is not visible here we can only guess.

Answer 2

I solve my issue by using using (ImageAttributes wrapMode = new ImageAttributes()) inside and upload image size must more than 415x415 , not sure why, but upload lower than 415x415 border will still appear and draw in correct position

protected byte[] ApplyResize(byte[] byteArray, int targetSize, Size originalSize = default(Size))
{
    using (MemoryStream ms = new MemoryStream(byteArray))
    {
        if (targetSize <= 0)
        {
            targetSize = 800;
        }

        var image = Image.FromStream(ms);
        var size = default(Size);
        if (originalSize != default(Size))
        {
            size = CalculateDimensions(originalSize, targetSize);
        }
        else
        {
            size = new Size(targetSize, targetSize);
        }

        var resized = new Bitmap(size.Width, size.Height);
        using (var graphics = Graphics.FromImage(resized))
        {
                graphics.CompositingQuality = CompositingQuality.HighSpeed;
                graphics.InterpolationMode = InterpolationMode.HighQualityBicubic;
                graphics.CompositingMode = CompositingMode.SourceCopy;
                var destination = new Rectangle(0, 0, size.Width, size.Height);
                using (ImageAttributes wrapMode = new ImageAttributes())
                {
                    wrapMode.SetWrapMode(WrapMode.TileFlipXY);
                    graphics.DrawImage(image, destination, 0, 0, originalSize.Width, originalSize.Height, GraphicsUnit.Pixel, wrapMode);
                }
        }
        using (var ms2 = new MemoryStream())
        {
            resized.Save(ms2, image.RawFormat);
            return ms2.ToArray();
        }
    }
}
