Question: How can I configure / tell Xcode's LLDB to not stop on - and pass a certain singal for a Commandline Tool?

Background:

We are using 3rd party code that relies on SIGUSR1.

Running in Xcode 13, LLDB stops on that signal and eats it (i.e. does not pass it).

Our targtet is a command-line tool, not an NSApplication.

I have found this answer to a very similar question (only difference AFAICS is that it is a NSApplication). It says to use this command:

process handle SIGUSR1 -n true -p true -s false

in a Symbolic Breakpoint, setting main() as symbol.

But that gives us:

error: invalid target, create a target using the 'target create' command

I have tried with a "normal" breakpoint in main():

enter image description here

And with a Symbolic Breakpoint, using main() as symbol:

enter image description here

Both breakpoints log the described error, so that proves:

  • the breakpoint does work
  • the command is processed but causes the error

The Xcode scheme used is setup for debug and the correct executable:

enter image description here

When using the command in LLDB - console (instead of Xcode), it works fine, so the command seems to be OK.

HowTo Simple Reproduce:

  • In Xcode, "new Project" -> "Comman Line Tool"

  • Name it "TestLLDB" and save anywhere

  • set breakpoint in main() line 13 (NSLog...)

  • Edit the the breakpoint and add "Debugger Command" Action: "process handle SIGUSR1 -n true -p true -s false"

  • Run the project

  • check the console for the above error

shallowThought
  • 19,212
  • 9
  • 65
  • 112
  • You can't call "process handle" until you have an actual process. That's why the answer you quote says to put the "process handle" command into a breakpoint command on main, at that point there will be a running process. But from the error, it sounds like you don't even have a target yet (created with the 'file' - i.e. 'target create' - command). But I'd have to see a complete session to tell in more detail what's going on. – Jim Ingham Dec 08 '21 at 18:46
  • @JimIngham: re "put the "process handle" command into a breakpoint command on main, at that point there will be a running process": that is exactly what I am doing (as written in the question. Sorry for being mistakable). I _do_ put the command in a breakpoint. And that gives me the error. Using LLDB in command line it works fine. – shallowThought Dec 10 '21 at 17:43
  • Can you put your exact breakpoint command in the question? The "invalid target" error doesn't make sense if you are in a breakpoint command, where you obviously have a target or you couldn't hit the breakpoint... – Jim Ingham Dec 10 '21 at 19:28
  • @JimIngham I agree that it doesn't make sense, that's why I am asking here desperately :-) . Thanks for having a look, I have updated the question with imgs of the used breakpooints. – shallowThought Dec 15 '21 at 10:16
  • Sorry, I cannot reproduce the behavior you report. I followed your steps and the process handle command works correctly. Probably time to file a bug with a copy of your project. Since this is Xcode related, it's best to report to http://bugreporter.apple.com. – Jim Ingham Dec 15 '21 at 19:21
  • @JimIngham I am on Xcode 13.0. What version r u using? (will file a bug when still occurring with latest Xcode but r curious). Thx again, really appreciate. – shallowThought Dec 16 '21 at 17:26
  • Also Xcode 13.0 – Jim Ingham Dec 16 '21 at 18:41

0 Answers0
