So I'm studiying pytorch coming from a background with tensorflow. I'm trying to replicate a simple convnet, that I've developed with success in tensorflow, to classify cat vs dogs images.

In pytorch I see some strange behaviors:

  1. Using a Learning Rate of 0.001 make the CNet predicting only 0 after the first batch (might be exploding gradients?)
  2. Using a Learning Rate of 0.0005 gives a smooth learning curve and the CNet converge

Can anyone help me to understand what I'm doing wrong? that the code:

import pathlib

import torch
import torch.nn.functional as F
import torchvision
from torch.utils.data.dataloader import DataLoader
import numpy as np

device = torch.device("cuda" if torch.cuda.is_available() else "cpu")

class CNet(torch.nn.Module):
    def __init__(self):
        super(CNet, self).__init__() #input is 180x180 image
        self.conv1 = torch.nn.Conv2d(3, 32, 3)  # out -> 178x178x32
        self.conv2 = torch.nn.Conv2d(32, 64, 3)
        self.conv3 = torch.nn.Conv2d(64, 128, 3)
        self.conv4 = torch.nn.Conv2d(128, 256, 3)
        self.conv5 = torch.nn.Conv2d(256, 256, 3)

        self.flatten = torch.nn.Flatten()

        #self.fc = torch.nn.LazyLinear(1)
        self.fc = torch.nn.Linear(7*7*256, 1)

    def forward(self, x):
        x = F.max_pool2d(F.relu(self.conv1(x)), (2, 2))
        x = F.max_pool2d(F.relu(self.conv2(x)), (2, 2))
        x = F.max_pool2d(F.relu(self.conv3(x)), (2, 2))
        x = F.max_pool2d(F.relu(self.conv4(x)), (2, 2))
        x = F.relu(self.conv5(x))

        x = self.flatten(x)
        o = torch.sigmoid(self.fc(x))
        return o


def train(model : CNet, train_data : DataLoader, criterion, optimizer : torch.optim.Optimizer, epochs = 10, validation_data : DataLoader = None):
    losses = []
    for epoch in range(epochs):
        epoch_loss = 0.0
        running_loss = 0.0
        for i, data in enumerate(train_data, 0):
            imgs, labels = data
            imgs, labels = imgs.to(device), labels.to(device, dtype=torch.float)
            labels = labels.unsqueeze(-1)

            # run
            output = net(imgs)

            # zero out accumulated grads
            loss = criterion(output, labels)

            optimizer.zero_grad()
            loss.backward()
            optimizer.step()

            running_loss += loss.item()
            epoch_loss += loss.item()
            #if i % 50 == 49:
              #  print(f'[{epoch+1}, {i:5d}] loss: {running_loss / 50.0:.3f}')
              #  running_loss = 0.0
        losses.append(epoch_loss / len(train_data.dataset))
        print(f'[{epoch+1}, {epochs:5d}] loss: {losses[-1]:.3f}')
    return losses


if __name__=="__main__":

    transforms = torchvision.transforms.Compose([
        torchvision.transforms.Resize((180, 180)),
        torchvision.transforms.ToTensor(),
    ])

    dataset_dir = pathlib.Path("E:\Datasets\\torch\Cat_Dog\cats_vs_dogs_small")
    train_data = torchvision.datasets.ImageFolder(dataset_dir / "train", transform=transforms)
    validation_data = torchvision.datasets.ImageFolder(dataset_dir / "validation", transform=transforms)
    test_data = torchvision.datasets.ImageFolder(dataset_dir / "test", transform=transforms)

    train_data_loader = DataLoader(train_data, batch_size=32, shuffle=True, num_workers=2, persistent_workers=True, pin_memory=True)
    validation_data_loader = DataLoader(validation_data, batch_size=32, num_workers=2, shuffle=True, pin_memory=True)
    test_data_loader = DataLoader(test_data, batch_size=32, shuffle=True, pin_memory=True, num_workers=2)


    import matplotlib.pyplot as plt

    #plt.figure()
    #for i in range(1, 10):
    #    plt.subplot(3, 3, i)
    #    plt.axis('off')

    #    rand_idx = np.random.random_integers(0, len(train_data))
    #    plt.imshow(np.moveaxis(test_data[rand_idx][0].numpy(), 0, 2))
    #plt.show()


    net = CNet()
    net = net.to(device)

    criterion = torch.nn.BCELoss()
    optimizer = torch.optim.RMSprop(net.parameters(), 0.001)

    net.train()

    # TODO save best model

    losses = train(net, train_data_loader, criterion, optimizer, epochs=30)
    epochs = range(1, len(losses) + 1)
    plt.plot(epochs, losses, 'bo', label='Training Loss')
    plt.show()


    print('Training Finished')
    correct_count, all_count = 0, 0
    for images,labels in test_data_loader:
        images,labels = images.to(device), labels.to(device, dtype=torch.float)
        with torch.no_grad():
            ps = net(images)

        pred_label = (ps > 0.5).to(torch.float)
        true_label = labels.unsqueeze(1)
        correct_count += (pred_label == true_label).sum().item()
        all_count += len(labels)

    print("Number Of Images Tested =", all_count)
    print("\nModel Accuracy =", (correct_count/all_count))

and here some screenshot of the loss for each point:

  1. LR=0.001 (not convering on pytorch, converging on tensorflow)enter image description here
  2. LR=0.0005 (converging in 30 epochs) [I know that the validation loss is not 0, accuracy is ~70% but is expected]enter image description here

As you can see the loss on the two experiment are very different in scale. What might cause that such a weird behavior? I call it 'wierd' cause I never seen that happen on tensorflow. Is typicall such different behavior between those 2 framework? or am I loosing something?

Levenlol
  • 305
  • 5
  • 17
  • Are you sure the learning rate is the only element you changed between those two experiments? – Ivan Sep 27 '22 at 09:26
