What is the memory format when writing an array, where the name of the array is a pointer, And what is the mechanism in that? C/C++

Question

!!The question is a little long, so I divided it into 4 parts, so that the reader would not be distracted!! I got a piece of information recently, that the name of the array in C/C++ is a pointer to the first element in the array, and that was from an AI (Chat GPT 3.5 and 4) and my tutor at university. And when I was looking at the memory locations for each of the pointer (the name of the array) and the first element and the address stored in the pointer, I found that they are all equal.

#include<iostream>
using namespace std;
int main (){
  int arr[3]{1,2,3};
  cout << &(arr)   <<"   "<<&arr[0]  <<"   "<< arr  <<endl;
  return 0;
}
/*
Output:
0x69fee0   0x69fee0   0x69fee0
*/

And here lies the first point or problem, how is the address of the pointer equal to the address that the pointer stores, as if we say a pointer points to itself and this will become an endless loop.

When I searched for the answer to this question, I found some specialists saying that the name of the matrix is not an indicator at all. Here is the second point.

When I searched more and more, I found an answer that says: It is true that the pointer has the same address followed by its value, but this does not mean that the pointer is located in the same memory space, He said that the bit space varies, which is inferred by the following program:

#include<iostream>
using namespace std;
int main (){
  int arr[3]{1,2,3};
  cout << &(arr)   <<"   "<<&arr[0]  <<"   "<< arr  <<endl;
  cout << &(arr)+1 <<"   "<<&arr[0]+1<<"   "<< arr+1<<endl;
  cout << &(arr)+2 <<"   "<<&arr[0]+2<<"   "<< arr+2<<endl;
  cout << &(arr)+3 <<"   "<<&arr[0]+3<<"   "<< arr+3<<endl;
  cout << sizeof(arr) <<"   "<<sizeof(&arr[0])<<"   "<< sizeof(&arr)<<endl;
  return 0;
}ٍ
/*
Output:
0x69fee0   0x69fee0   0x69fee0
0x69feec   0x69fee4   0x69fee4
0x69fef8   0x69fee8   0x69fee8
0x69ff04   0x69feec   0x69feec
12   4   4
*/

And This was the third point.

Regarding the fourth and most important point: It is that I deduced the shape of the memory through the outputs of the previous program, as we do in the science of logical circuits deducing the circuit through the outputs. And I want you to see if the drawing (unscientific, but to bring the idea closer) is correct in its general idea, and any comments on it are very important to me, because I am really interested in how the memory will look in the event that the name of the matrix is a pointer. Finally, when you see the drawing, there is an important question: Is the memory in the RAM really divided into two halves, as shown in the drawing? Which half of the pointer and half of the matrix, and if that is true, what is the mechanism?

diagram :

Answer 1

arr, &arr[0] and &arr will have the same value:

• arr printed value is the (implicit address of the) array
• &arr printed value is the explicit address of the array.
• &arr[0] printed value the address of the first element of the array, which is the same as the address of the array

But when the index is different:

• arr is an array of three integers.
• arr + 1 is the address of the array plus sizeof(int) it is the same as &arr[1]
• &arr + 1 is the address of the array + sizeof(arr) in our case it is equivalent to arr+3, it is the same as (&arr)[1]

Answer 2

Beware of the types!

First, may be many of the expressions have the same value, but not of the same type; 1 orange is not 1 banana.

Second, there is no pointer there, only addresses. A pointer is a variable in which you can store an address. An address is a (typed) value. A pointer is a (typed) storage.

arr is the array (of type int[3], i.e. sizeof(arr)==3*sizeof(int)), not a pointer to the first element of the array. If it had been a pointer you would have been able to write arr++, or arr = p(for some other pointer int *p) which is forbidden. arr is the array, just like i is an int in int i (i is not a pointer right?). typeid(arr).name() would give something like A3_i (array of three ints).

&arr is the address of the array. If you make arithmetic with that address, then it is in terms of sizeof(arr). (&arr)+1 (or &arr+1) is the address just after the (whole) array arr. typeid(&arr).name() would give something like PA3_i(pointer to array of three ints).

&(arr[0]) (or &arr[0]) is the address of the first element of arr then an address of type int *. typeid(&arr[0]).name() would give Pi (pointer to int).

Now arrays can decay to pointers in many contexts (argument passing, pointer assignment, pointer arithmetic, ...). That means that arr can be viewed as the address of its first element, i.e. arr is viewed as &arr[0] so as an int *. For example, you can write int *p = arr or arr+1. That doesn't mean that arr is a pointer, just that in this context arr is considered as the address of its first element. Remark that it is exactly the case when you make cout << arr (arr decays as you saw an address not an array...).

Note that array can decay to pointer... is somehow misleading, it should have been much better to say array decay to address... (IMHO).
