I need to plot a few columns from my dataframe. Generally speaking, in this chart, I need the values of the three selected columns to be plotted as one row, where X will represent the Release column, as per the following dataframe:

Release,AddedClasses,ModifiedClasses,RemovedClasses,AddedMethods,ModifiedMethods,RemovedMethods,AddedImports,RemovedImports,AddedFields,ModifiedFields,RemovedFields
v1,39,33,0,43,25,0,3,0,21,0,0
v2,48,62,0,88,56,1,35,0,42,0,2
v3,54,93,0,117,95,1,67,0,67,0,2
v4,55,116,29,124,134,5,69,2,121,0,5

For rows, I need to plot values from the following columns: AddedClasses, ModifiedClasses, RemovedClasses.

I tried to plot the graph with the following code:

ggplot(data=ReminderDOPTransformationsResume, aes(x=Release, group = 1)) +
geom_line(aes(y=AddedClasses,color=AddedClasses), size=2) +
geom_point(aes(color = AddedClasses), size=5, stroke = 0, shape = 16) +
geom_line(aes(y=ModifiedClasses,color=ModifiedClasses), size=2) +
geom_point(aes(color = ModifiedClasses), size=5, stroke = 0, shape = 16) +
geom_line(aes(y=RemovedClasses,color=RemovedClasses), size=2) +
geom_point(aes(color = RemovedClasses), size=5, stroke = 0, shape = 16) +
scale_linetype_manual(values=c("solid", "solid")) +
theme_bw(base_size = 24) + theme(plot.title = element_text(hjust = 0.5), legend.title=element_blank())

But when executing, the following error is displayed:

Error: geom_point requires the following missing aesthetics: y

If I remove the geom_point parts, the graph is plotted, but there are errors in line colors and captions:

enter image description here

Leomar de Souza
  • 677
  • 10
  • 23
  • 2
    Quick hint: adding multiple geom statements is a sure sign that your data should be reshaped from wide to long format. Also, please provide example data in a plain text format, not as images, so users can copy/paste it. – neilfws Aug 14 '19 at 23:24
  • 1
    @neilfws Thanks for the quick tips. I updated a description to insert the dataframe code. – Leomar de Souza Aug 14 '19 at 23:44

1 Answers1

2

Transform your data from "wide" to "long" format - one column for variable names, another for their values - and aes() will do all the work for you.

library(dplyr)
library(tidyr)
library(ggplot2)

ReminderDOPTransformationsResume <- tibble(Release = paste0("v", 1:4),
                                           AddedClasses = c(39, 48, 54, 55),
                                           ModifiedClasses = c(33, 62, 93, 116),
                                           RemovedClasses = c(0, 0, 0, 29),
                                           AddedMethods = c(43, 88, 117, 124))

ReminderDOPTransformationsResume %>%
  select(Release, AddedClasses, ModifiedClasses, RemovedClasses) %>%
  gather(Var, Val, -Release) %>%
  ggplot(aes(Release, Val, group = Var)) +
  geom_line(aes(color = Var)) +
  geom_point(aes(color = Var))

Result:

enter image description here
