Xcode building for iOS Simulator, but linking in an object file built for iOS, for architecture 'arm64'

Question

I am trying to get a large (and working on Xcode 11!) project building in Xcode 12 (beta 5) to prepare for iOS 14. The codebase was previously in Objective-C, but now it contains both Objective-C and Swift, and uses pods that are Objective-C and/or Swift as well.

I have pulled the new beta of CocoaPods with Xcode 12 support (currently 1.10.0.beta 2).

Pod install is successful. When I do a build, I get the following error on a pod framework:

building for iOS Simulator, but linking in object file built for iOS, for architecture arm64

and possibly also the error:

Unable to load standard library for target 'arm64-apple-ios11.0'

When I go run lipo -info on the framework, it has: armv7s armv7 i386 x86_64 arm64.

Previously, the project had Valid Architectures set to: armv7, armv7s and arm64.

In Xcode 12, that setting goes away, as per Apple's documentation. Architectures is set to $(ARCHS_STANDARD). I have nothing set in excluded architectures.

What may be going on here? I have not been able to reproduce this with a simpler project yet.

Answer 1

Basically, you have to exclude arm64 for the simulator architecture, both from your project and the Pod project.

• To do that, navigate to Build Settings of your project and add Any iOS Simulator SDK with value arm64 inside Excluded Architecture.



OR

• If you are using custom XCConfig files, you can simply add this line for excluding simulator architecture.

  EXCLUDED_ARCHS[sdk=iphonesimulator*] = arm64


  Then

  You have to do the same for the Pod project until all the Cocoa pod vendors are done adding following in their Podspec.

  s.pod_target_xcconfig = { 'EXCLUDED_ARCHS[sdk=iphonesimulator*]' => 'arm64' }
  s.user_target_xcconfig = { 'EXCLUDED_ARCHS[sdk=iphonesimulator*]' => 'arm64' }


  You can manually add the Excluded Architecture in your Pod project's Build Settings, but it will be overwritten when you use pod install.

  In place of this, you can add this snippet in your Podfile. It will write the necessary Build Settings every time you run pod install.

  post_install do |installer|
    installer.pods_project.build_configurations.each do |config|
      config.build_settings["EXCLUDED_ARCHS[sdk=iphonesimulator*]"] = "arm64"
    end
  end


Answer 2

TL;DR;

Set "Build Active Architecture Only (ONLY_ACTIVE_ARCH)" to Yes for your libraries/apps, even for release mode.

---

While trying to identify the root cause of the issue I realized some fun facts about Xcode 12.

1. Xcode 12 is actually the stepping stone for Apple silicon which unfortunately is not yet available (when the answer was written). But with that platform we are going to get an arm64-based macOS where simulators will also run on the arm64 architecture unlike the present Intel-based x86_64 architecture.

2. Xcode usually depends on the "Run Destination" to build its libraries/applications. So when a simulator is chosen as the "Run Destination", it builds the app for available simulator architectures and when a device is chosen as the "Run Destination" it builds for the architecture that the device supports (arm*).

3. xcodebuild, in the Xcode 12+ build system considers arm64 as a valid architecture for simulator to support Apple silicon. So when a simulator is chosen as the run destination, it can potentially try to compile/link your libs/apps against arm64 based simulators, as well. So it sends clang(++) some -target flag like arm64-apple-ios13.0-simulator in <architecture>-<os>-<sdk>-<destination> format and clang tries to build/link against an arm64-based simulator that eventually fails on an Intel based Mac.

4. But xcodebuild tries this only for Release builds. Why? Because, "Build Active Architecture Only (ONLY_ACTIVE_ARCH)" build settings is usually set to "No" for the "Release" configuration only. And that means xcodebuild will try to build all architectural variants of your libs/apps for the selected run destination for release builds. And for the Simulator run destination, it will includes both x86_64 and arm64 now on, since arm64 in Xcode 12+ is also a supported architecture for simulators to support Apple silicon.

Simply putting, Xcode will fail to build your application anytime it tries the command line, xcodebuild, (which defaults to release build, see the general tab of your project setting) or otherwise and tries to build all architectural variants supported by the run destination. So a simple workaround to this issue is to set "Build Active Architecture Only (ONLY_ACTIVE_ARCH)" to Yes in your libraries/apps, even for release mode.

If the libraries are included as Pods and you have access to .podspec you can simply set:

spec.pod_target_xcconfig = { 'ONLY_ACTIVE_ARCH' => 'YES' }

spec.user_target_xcconfig = { 'ONLY_ACTIVE_ARCH' => 'YES' } # not recommended

I personally don't like the second line since pods shouldn't pollute the target project and it could be overridden in the target settings, itself. So it should be the responsibility of the consumer project to override the setting by some means. However, this could be necessary for successful linting of podspecs.

However, if you don't have access to the .podspec, you can always update the settings during installation of the pods:

post_install do |installer|
  installer.pods_project.targets.each do |target|
    target.build_configurations.each do |config|
      config.build_settings["ONLY_ACTIVE_ARCH"] = "YES"
    end
  end
end

One thing I was concerned about that what will be the impact of this when we actually archive the libraries and applications. During archiving applications usually take the "Release" configuration and since this will be creating a release build considering only the active architecture of the current run destination, with this approach, we may lose the slices for armv7, armv7s, etc. from the target build. However, I noticed the documentation says (highlighted in the attached picture) that this setting will be ignored when we choose "Generic iOS Device/Any Device" as the run destination, since it doesn't define any specific architecture. So I guess we should be good if we archive our app choosing that as a run destination.

Answer 3

I found a solution! SwiftUI Previews not working with Firebase

If you set excluded architectures for the simulator to arm64 it will compile.

Answer 4

The proposed answers are outdated/incorrect.

You should initially try to update both CocoaPods and the dependencies for your library/app, and then, if that doesn't work, contact the vendors of any dependencies you are using to see if they have an update in progress to add support for arm64 Simulator slices on M1 Macs.

There are a lot of answers on here marked as correct suggesting that you should exclude arm64 from the list of supported architectures. This is at best a very temporary workaround, and at worst it will spread this issue to other consumers of your libraries. If you exclude the arm64 Simulator slice, there will be performance impacts on apps that you're developing in the Simulator (which in turn can lead to reduced battery time for your shiny new M1 kit while you're developing your amazing ideas).

Answer 5

The Valid Architectures build setting has been removed in Xcode 12. If you had values in this build setting, they're causing a problem and need to be removed.

I was able to "clear out" the VALID_ARCHS build setting by adding it back in as a user-defined build setting (with no values), running the project (which failed), and then deleting the VALID_ARCHS build setting. After that, I was able to run on the simulator.

My Architectures build setting is Standard Architectures.

You can add a user-defined setting from the plus button in Build Settings:

Answer 6

Hidden Gem in all these answers

I had changed "Excluded Architectures" in my target for the main project, but not for the PODS project. It is a truly hidden gem. I have been with this problem for weeks now.

Answer 7

Easy fix

1. Right click on xcode in Applications folder
2. Get info
3. Select "Open using Rosetta"

Run.

Xcode get info

Answer 8

Xcode 12.3

I solved this problem by setting Validate Workspace to Yes

Answer 9

After trying and searching different solutions, I think the most safest way is adding the following code at the end of the Podfile

post_install do |pi|
   pi.pods_project.targets.each do |t|
       t.build_configurations.each do |bc|
          bc.build_settings['ARCHS[sdk=iphonesimulator*]'] =  `uname -m`
       end
   end
end

This way you only override the iOS simulator's compiler architecture as your current cpu's architecture. Compared to others, this solution will also work on computers with Apple Silicon.

Answer 10

Preface

When you build an app, you build for a specific platform and CPU Architecture combination.

iOS Platforms:

• iOS device "generic/platform=iOS"
• Simulator "generic/platform=iOS Simulator"

_{Note: There a whole lot more platforms. For brevity I’m just focused on iOS platforms. Otherwise there are macOS, watchOS, tvOS, visionOS platforms.}

CPU Architectures:

• arm64
• x86_64

This is because a macOS vs iOS vs iOS simulator will use different libraries. See How does building for iOS device and simulator actually differ?

And different CPU Architectures use different CPU instructions.

This ultimately means the built binary and the environment (device/simulator) you're running it in, will need to match. Otherwise some system libraries won't exist on the operating system, or the CPU instructions can't get processed.

Will you always be building for one combination?

No. If you're using a Release config, then you'll end up archiving your product for BOTH arm64 and x86_64 architectures.

During the archive process (often in your CI/CD) then things will fail because the simulator architectures are selected as well.

Yet a 'Debug' builds onto your physical devices won't attempt to build for a different platform or architecture. It's because it prioritizes 'development speed' over 'complete correctness'.

The default Xcode ONLY_ACTIVE_ARCH settings for this are:

I have an Intel MacBook. If I don't exclude any architecture and platform, what will happen?

• If you're building a debug config, then it will only build for the CPU architecture of the destination's platform. Meaning:

  • If you're building into your iPhone, you'll just need to support ARM64
  • If you're building into a simulator, you'll just need to support X86_64

• If you're building a release config, then it will:

  • Build for both platforms and all possible architectures.

I have an M1 MacBook. If I don't exclude any architecture and platform, what will happen?

• If you're building a debug config, then it will only build for the CPU architecture of the destination's platform. Meaning:

  • If you're building into your iPhone, you'll just need to support ARM64
  • If you're building into a simulator, you'll just need to support ARM64
  • Alternatively you can enable Rosetta for Xcode. In that case if you're building into a simulator, then you need to support X86_64 as well.

• If you're building a release config, then will: - Build for both platforms and all possible architectures.

Why is it different for Release builds?

During active development, you want to build things fast. It doesn't make sense for you to actively build architectures you don't need to use. That means if you're building into a device, then you only want to build for that platform-architecture combo. You don't want to build the other combinations.

However if you're releasing it — for others. Then because you don't want to limit/dictate how they build your app, then you have to build for all possible combinations and make sure your framework compiles for all of them.

For an app it may make less sense to make an archive for the simulator platform, however for a framework, your consumer is another developer. That developer will be building your framework into a simulator and into a real device. Hence you need to support both platforms and architectures.

Is CocoaPods the source of the problem?

It depends. If the pod has excluded a certain architecture, and you're trying to build for that architecture, then you have to ask the pod owner to not excluded it.

Otherwise if all of your pods are supporting the given platform/architecture that you're trying to build for, then it's a problem from within the code you you wrote yourself in your host app.

Solution

Update pre-compiled libraries with Apple silicon support

If the library named in the error message is from a vendor, see Update pre-compiled libraries from vendors. If you have source code for the library, rebuild the library as an XCFramework with support for the simulator on Apple silicon. To learn how to build an XCFramework, see Creating a multiplatform binary framework bundle.

Update pre-compiled libraries from vendors

If the library producing the build error is a pre-compiled library from a vendor and you don’t have the source code, contact the vendor for an updated XCFramework supporting Apple silicon. If an update isn’t available from the vendor, temporarily use the EXCLUDED_ARCHS build setting to exclude arm64 for the simulator SDK as shown in the figure below. Do not exclude arm64 for any other SDK.

From Docs

More Questions in regard to the outcome of the solution:

What happens if I exclude ARM64 for the 'iOS Simulator' Platform?

You won't be able to build into M1 simulators directly. You'd have to Use Xcode with Rosetta on M1 then. Which is a hack and is slightly slower.

What happens if I exclude X86 for the 'iOS Simulator' Platform?

You won't be able to build into Intel based simulators. Nor you'd be able to build into a simulator using Rosetta.

What happens if exclude ARM64 for the 'iOS' Platform?

You won't be able to build into physical devices. Nor archive for them. Terrible idea!

So I should exclude architectures?

Strive for your app, including all of its pre-compiled libraries, to always build for the complete set of architectures defined by the default value of the ARCHS build setting. Only use the EXCLUDED_ARCHS build setting on targets where the final released app is not using the target’s functionality on a specific architecture, such as a Mac app that only supports a legacy feature on Intel-based Mac computers. Do not modify the ARCHS build setting to achieve the same result.

Additionally in big teams, some developers may be on an M1, while some others are on older Intel based MacBooks. You never know maybe some day there'd be an M5 Macbook, that will have a distinct architecture. So it's good to be considerate of how you make your project/product/framework compatible for your own devs and your library consumers.

Do we have an iOS device with Intel X86_64?

Such a thing doesn't exist.

How do inspect a binary?

lipo -info <path-to-binary>

On the arm64 directory within an xcframework packaging, I see:

Non-fat file: /Users/mfaani/Video.xcframework/ios-arm64/Video.framework/Video is architecture: arm64

For the sims I see:

Architectures in the fat file: /Users/mfaani/Video.xcframework/ios-arm64_x86_64-simulator/Video.framework/Video are: x86_64 arm64

You can go into your mac's /Applications, right click; 'show Package Contents' for any app; find the app's associated binary. And then inspect it using lipo.

To be clear, a framework or an app can both be inspected with lipo. Similarly if you access the build folder on the simulator, you can inspect the binary as well.

What's the difference between an XCFramework and a FAT binary?

• A FAT binary, is just a binary — with two (or more) architectures combined into a single binary. It's just named FAT because it's fattened. It's other names are 'multi-architecture binary' or universal binary.
• An XCFramework is just a structured folder, a wrapper. Nothing more. That has distinct folders per platform. Within each folder there's a binary. That binary can be FAT binary or non-FAT (single architecture).

Also note, a FAT binary can be either a framework or the binary of an app. An XCFramework is just a framework. It's never the app itself.

Does my app get bloated with all the other platforms-architecture combinations I don't need?

XCFramework won't bloat app store submissions, because an archive for the iOS device will just pick up each framework from a directory that's isolated from simulator platform.

However with FAT binaries, given that it was just a single binary, you had to thin/slice the dependencies before submitting to Apple store. Otherwise you'd get the following error:

Unsupported Architecture. Your executable contains unsupported architecture '[x86_64, i386]'."

For more on that and its previous solution, see here

To be perfectly clear, this was an issue in pre-xcode 12. But not every project setup would face this. You'd only face this if you had some pre-compiled dependency from a vendor (who didn't share their source code, but just shared the FAT binary so you can build the app for both device and sim), otherwise if you had access to the source code then your archive wouldn't contain compilations for both architectures. It would only contain binaries for targeted architecture.

Also see this great blog post for about some more details and historical context.

What does the Folder structure of a FAT look like?

It's just a binary. It's not a folder. The binary works for two or more architectures.

What does the Folder structure of an xcframework look like?

ios-arm64
   - binary
ios-arm64_x86_64-simulator
   - (FAT) binary

If an XCFramework is made to work with mac Catalyst then the folder structure would be like:

ios-arm64
    - binary
ios-arm64_x86_64-simulator
    - (FAT) binary
ios-x86_64-maccatalyst
    - binary

For a more comprehensive list of possible platforms. See XCFrameworsk: Demonstration of creating and integrating xcframeworks and their co-op with static libraries and Swift packages

Why doesn't my vendor support ios-arm64-simulator?

It could be for a number of reasons.

• migration effort: Often it's just that when the compiled they didn't have an M1, and it's been a long time since they've compiled and if they compile they have to make some changes. Like you have to understand it's been years that that there wasn't a need for a new architecture-platform combination. So this is new and not everyone understands it. The fact that Swift is now ABI compatible with its previous versions reduce the need for framework owners to recompile their app with every new Swift release. So they could go on years without the need to recompile...
• limitation: The pre-compiled library depends on another pre-compiled library which isn't compiled for arm64-sim.
• The owner of the framework doesn't have an Apple Silicon (arm64) machine. Or the person who knows about those stuff has left the company.

Any last words?

Make sure you look into ALL Project AND Target AND Pod Project AND Pod Target settings. If one of them excludes a certain architecture then you can't build your app for that architecture. Often this could be in your Podfile.

Or if the pod/framework is being compiled in a totally different repo, then the settings that you have set there, are what matters the most.

If you pay attention to the error message you get, it should be easy to navigate your way to the target that doesn't support. Once you identify the target, then you have to identify when/where it gets compiled using the notes in the two paragraphs above.

Answer 11

For me the following setting worked:

Build Settings → Excluded Architectures.

I added "arm64" to both Release and Debug mode for the "Any iOS Simulator SDK" option.

Answer 12

Go to Targets section, select each target and do the following:

• Set Build Active Architecture Only to YES
• Add Excluded Architectures and set its value to arm64 (See attached)
• Set Active scheme (on toolbar next to project name) to any iOS Simulator
• Clean Build folder from Product Menu and build.

Answer 13

As of Sep 19, 2022, none of the existing answers worked for me. Most answers suggests to exclude arm64 from build settings, after this is done, it gives fatal error: module map file not found

What worked for me is to open Xcode using Rosseta,

1. Right click on Xcode in applications folder
2. Get Info
3. Check Open using Rosetta
4. Open Xcode
5. Open project
6. Clean build folder
7. Run project

By opening Xcode using Rosseta, no other build settings or configurations are needed.

This is probably not a long time solution, but for quickly addressing the issue. After upgrading to MAC OS 13.5 with Xcode 14.3.1, there is no more open with Rosseta option anymore, but you do the following to run it on Rosseta.

1. Go to “Product” in the menu bar
2. Destination
3. Destination Architectures
4. Show both
5. Pick a simulator from the device dropdown menu that has Rosseta next to it.
6. Run project.

References:

• https://medium.com/timeless/starting-react-native-project-in-apple-mac-m1-chip-system-28da0c1f2132
• https://developer.apple.com/forums/thread/670006
• https://armen-mkrtchian.medium.com/run-rosetta-simulator-on-xcode-14-3-381d341364ee

Answer 14

Xcode Version 13.2.1 and macOS Monterey 12.0.1

Almost everybody is facing the same issue with old projects and pods after switching to new M1 chip system.

"in /Users//Desktop/_iOS_app/Pods/iOS/framework/(CLSInternalReport.o), building for iOS Simulator, but linking in object file built for iOS, file '/Users/y/Desktop/_iOS_app/Pods/iOS/.framework/for architecture arm64"

I have come to a solution which is working perfectly.

First thing first, to all the developer who are suggesting exclude arm64 for your project will work yes it will compile but after installation when you try to open it, it will show a popup with the message, "the developer of this App needs to be update it to work with this version of iOS". This is because as per apple "In iOS 11 and later, all apps use the 64-bit architecture" and if you exclude arm64 for your project it will not open App on iOS 11 and later.

So instead of selecting whole project only excluded architectures for the simulator to arm64.

Steps: On top of project files, Select target > build setting > architecture > excluded architecture. now add select "any iOS simulator SDK" and give it a value arm64.

See the image below for refrence.

Answer 15

If you have trouble in Xcode 12 with simulators, not real device, yes you have to remove VALID_ARCHS settings because it's not supported anymore. Go to "builds settings", search "VALID_ARCHS", and remove the user-defined properties. Do it in every target you have.

Still, you may need to add a script at the bottom of your podfile to have pods compiling with the right architecture and deployment target:

post_install do |installer|
  installer.pods_project.targets.each do |target|
    target.build_configurations.each do |config|
      config.build_settings.delete 'IPHONEOS_DEPLOYMENT_TARGET'
      config.build_settings['ONLY_ACTIVE_ARCH'] = 'NO'
     end
  end
end

Answer 16

I solved the problem by adding "arm64" in "Excluded Architectures" for both the project target and pod target.

Xcode → Target Project → Build Setting → Excluded Architectures → *"arm64"

Xcode → Pod Target → Build Setting → Excluded Architectures → *"arm64"

Answer 17

I found that

1. Using Rosetta (Find Xcode in Finder > Get Info > Open using Rosetta)
2. Build Active Architecture Only set to YES for everything, in both Project and Target
3. (You might not need it, read comment below) And including this in the podfile:

post_install do |installer|
  installer.pods_project.targets.each do |target|
    target.build_configurations.each do |config|
      config.build_settings["ONLY_ACTIVE_ARCH"] = "YES"
    end
  end
end

worked for me.

We had both Pods and SPM and they didn't work with any of the combinations of other answers. My colleagues all use Intel MacBooks and everything still works for them too!

Answer 18

After upgrading to Xcode 12 I was still able to build for a real device, but not the simulator. The Podfile build was working only for the real device.

I deleted VALID_ARCHS under Build Settings > User-Defined and it worked! Bashing my head for some time before finding this.

Answer 19

1.Add arm64 to Build settings -> Exclude Architecture in all the targets.

2.Close Xcode and follow the steps below to open

1. Right-click on Xcode in Finder
2. Get Info
3. Open with Rosetta

Answer 20

I was having issues building frameworks from the command line. My framework depends on other frameworks that were missing support for ARM-based simulators. I ended up excluding support for ARM-based simulators until I upgrade my dependencies.

I needed the EXCLUDED_ARCHS=arm64 flag when building the framework for simulators from the command line.

xcodebuild archive -project [project] -scheme [scheme] -destination "generic/platform=iOS Simulator" -archivePath "archives/[scheme]-iOS-Simulator" SKIP_INSTALL=NO BUILD_LIBRARY_FOR_DISTRIBUTION=YES EXCLUDED_ARCHS=arm64

Answer 21

Xcode 12

Removing VALID_ARCH from Build settings under User-Defined group work for me.

Answer 22

Starting from Xcode 14.3, simply do this. Go to Product -> Destination -> Destination Architectures and select show Both. So now you can see Rosetta simulators on your destination.

Answer 23

I believe I found the answer. Per the Xcode 12 beta 6 release notes:

"The Build Settings editor no longer includes the Valid Architectures build setting (VALID_ARCHS), and its use is discouraged. Instead, there is a new Excluded Architectures build setting (EXCLUDED_ARCHS). If a project includes VALID_ARCHS, the setting is displayed in the User-Defined section of the Build Settings editor. (15145028)"

I was able to resolve this issue by manually editing the project file (I could not figure out how to remove the item from the project file using Xcode) and removing all lines referring to VALID_ARCHS. After that, I am able to build for the simulator fine.

Answer 24

Go to finder -> Applications -> Xcode -> Right click on Xcode -> Select open using rosetta

Answer 25

In your xxx.framework podspec file, add the following configuration. Avoid a pod package that contains arm64 simulator architectures.

s.pod_target_xcconfig = { 'EXCLUDED_ARCHS[sdk=iphonesimulator*]' => 'arm64' }
s.user_target_xcconfig = { 'EXCLUDED_ARCHS[sdk=iphonesimulator*]' => 'arm64' }

Answer 26

After trying almost every answer to the question and reading through Apple developer forums I found only one solution worked for me.

I am building a universal framework that is consumed in a Swift app. I was unable to build to the simulator without architecture errors.

In my framework project I have a Universal Framework task in my build phases. If this is the case for you:

• Add the following to your xcodebuild task inside the build phase: EXCLUDED_ARCHS="arm64"

Next you have to change the following project Build Settings:

• Delete the VALID_ARCHS user defined setting
• Set ONLY_ACTIVE_ARCH to YES ***

*** If you are developing a framework and have a demo application as well, this setting has to be turned on in both projects.

Answer 27

Updates: Oct 2020

You can simply set arm64 only for Debug > Simulator - iOS 14.O SDK under Excluded Architecture.

Answer 28

Please, don't forget to clean the build folder after you add arm64 to excluded architecture.

You can do that by going to Menu > Product > Clean Build Folder or simply Command+Shift+K.

Answer 29

I was facing the same issue and trying to launch a React Native app on an M1 Mac. Note that my Intel Mac with the same project worked well without this error.

What solved the problem for me was to force Xcode to open through Rosetta.

To achieve this:

Right click on Xcode in Applications folder* → Get Info → check 'Open using Rosetta' checkbox.

Answer 30

Xcode 13.2.1, macOS v12 (Monterey), target iOS 14.0, and CocoaPods 1.11.2

I had a similar issue when including LogRocket and/or Plaid -- they are xcframeworks and work fine on my local, but they can't be built on bitrise. I'd tried all answers above:

• EXCLUDED_ARCHS arm64
• setting ONLY_ACTIVE_ARCH to YES in Podfile
• VALIDATE_WORKSPACE to YES
• setting ARCHS[sdk=iphonesimulator*] to uname -m in Podfile

None of them works.

But by specifying a target iOS version or deleting it would work:

post_install do |installer|
  installer.pods_project.targets.each do |target|
    target.build_configurations.each do |config|
      config.build_settings['IPHONEOS_DEPLOYMENT_TARGET'] = '14.0'
      # OR
      config.build_settings.delete 'IPHONEOS_DEPLOYMENT_TARGET'
    end
  end
end

Answer 31

Issue when compiling for the simulator:

Building for the iOS simulator, but linking in an object file built for iOS, for architecture arm64

Xcode 12.1, Pod 1.9.1

My project structure

• Main Target
• Share Extension
• Notification service extension
• Submodule, Custom Framework
• Podfile

1. Add arm64 to Build settings -> Exclude Architecture in all the targets.



2. Removed arm64 from VALID_ARCHS and added x86_64 in all the targets.



3. Add following code in podfile

   post_install do |installer|
       installer.pods_project.build_configurations.each do |config|
       config.build_settings["EXCLUDED_ARCHS[sdk=iphonesimulator*]"] = "arm64"
    end
   end


4. Did pod update, deleted podfile.lock, and did pod install

5. Do a clean build.

Answer 32

I was also experiencing the same issue with specific library that was installed through carthage. For those who are using Carthage, as Carthage doesn't work out of the box with Xcode 12, this document will guide through a workaround that works for most cases. Well, shortly, Carthage builds fat frameworks, which means that the framework contains binaries for all supported architectures. Until Apple Sillicon was introduced it all worked just fine, but now there is a conflict as there are duplicate architectures (arm64 for devices and arm64 for simulator). This means that Carthage cannot link architecture specific frameworks to a single fat framework.

You can follow the instruction here. Carthage XCODE 12

Then after you configure the Carthage. Put the arm64 in the "Excluded Architectures" on build settings.

Try to run your project using simulator. Simulator should run without any errors.

Answer 33

The problem here are the Valid architectures in Xcode 11. Open the project in Xcode 11 and change the Valid architectures value to $(ARCHS_STANDARD) for both your project, target and Pods. Reopen the project in Xcode 12 and build.

Answer 34

First, generate x86_64 for Pod projects!!!!

post_install do |installer|
    installer.pods_project.targets.each do |target|
        target.build_configurations.each do |config|
            config.build_settings['ARCHS'] = "arm64 x86_64"
        end
    end
end

Second, add "x86_64" for VALID_ARCHS.

_{I found this after trying a lot of useless answers online, and this works for me.}

Answer 35

Please make sure to provide the code or specific error message you are encountering, as it will help in providing a more accurate solution.

Regarding the provided information, it seems like you are trying to change the architecture of your app. To resolve this issue, you can follow the steps below:

Step 1: Open your project and navigate to the "Build Settings" tab.

Step 2: In the "Excluded Architectures" section, select "Yes" for the "Change Release" option.

Step 3: Under the "Debug" and "Release" tabs, click the "+" button and select the iOS simulator SDK.

Step 4: Choose "arm64" as the architecture for both debug and release configurations.

Please note that the specific steps may vary depending on your development environment and tools. If you encounter any issues or need further assistance, feel free to provide more details for a more accurate solution.

Answer 36

I was trying to build xcFramework when I faced this issue. Nothing was helping, but I managed to resolve this with lipo and am sharing my script:

OUTPUT_DIR_PATH="${PROJECT_DIR}/XCFramework"

function archivePathSimulator {
    local DIR=${OUTPUT_DIR_PATH}/archives/"${1}-SIMULATOR"
    echo "${DIR}"
}

function archivePathDevice {
    local DIR=${OUTPUT_DIR_PATH}/archives/"${1}-DEVICE"
    echo "${DIR}"
}

function archive {
    echo "▸ Starts archiving the scheme: ${1} for destination: ${2};\n▸ Archive path: ${3}.xcarchive"
    xcodebuild clean archive \
    -project "${PROJECT_NAME}.xcodeproj" \
    -scheme ${1} \
    -configuration ${CONFIGURATION} \
    -destination "${2}" \
    -archivePath "${3}" \
    SKIP_INSTALL=NO \
    OBJROOT="${OBJROOT}/DependentBuilds" \
    BUILD_LIBRARY_FOR_DISTRIBUTION=YES | xcpretty
}

# Builds archive for iOS simulator & device
function buildArchive {
    SCHEME=${1}

    archive $SCHEME "generic/platform=iOS Simulator" $(archivePathSimulator $SCHEME)
    archive $SCHEME "generic/platform=iOS" $(archivePathDevice $SCHEME)
}

# Creates xc framework
function createXCFramework {
    FRAMEWORK_ARCHIVE_PATH_POSTFIX=".xcarchive/Products/Library/Frameworks"
    FRAMEWORK_SIMULATOR_DIR="$(archivePathSimulator $1)${FRAMEWORK_ARCHIVE_PATH_POSTFIX}"
    FRAMEWORK_DEVICE_DIR="$(archivePathDevice $1)${FRAMEWORK_ARCHIVE_PATH_POSTFIX}"

    echo "Removing ${FRAMEWORK_SIMULATOR_DIR}/${1}.framework/${1}"

    if lipo "${FRAMEWORK_SIMULATOR_DIR}/${1}.framework/${1}" -verify_arch "arm64"; then
        echo "Removing arm64"
        lipo -remove "arm64" -output "${FRAMEWORK_SIMULATOR_DIR}/${1}.framework/${1}" "${FRAMEWORK_SIMULATOR_DIR}/${1}.framework/${1}"
    fi

    xcodebuild -create-xcframework \
               -framework ${FRAMEWORK_SIMULATOR_DIR}/${1}.framework \
               -framework ${FRAMEWORK_DEVICE_DIR}/${1}.framework \
               -output ${OUTPUT_DIR_PATH}/xcframeworks/${1}.xcframework
}

echo "#####################"
echo "▸ Cleaning the dir: ${OUTPUT_DIR_PATH}"
rm -rf $OUTPUT_DIR_PATH

DYNAMIC_FRAMEWORK="${PROJECT_NAME}"

echo "▸ Archive $DYNAMIC_FRAMEWORK"
buildArchive ${DYNAMIC_FRAMEWORK}

echo "▸ Create $DYNAMIC_FRAMEWORK.xcframework"
createXCFramework ${DYNAMIC_FRAMEWORK}

Answer 37

In my case, the error was thrown by GTMAppAuth which I was using with Google sign in my Flutter project.

Solution: You have to go to that package and click YES in Build Active Architecture Only.

Answer 38

In my case updating CocoaPods helped:

1. Uninstall CocoaPods if installed:

   sudo gem uninstall cocoapods


2. Install CocoaPods:

   brew install cocoapods


3. If you have a linking error:

   brew link --overwrite cocoapods`


4. Run pod install

Answer 39

Time saving salution.

Go to -> Applications -> Xcode -> Right-click on Xcode -> click on Get Info -> Select open using rosetta.

Please make sure it is in your pod file remove this. config.build_settings['ARCHS[sdk=iphonesimulator*]'] = uname -m

[]

if your problem is not resolved the try this also

delete all the highlighted files from your project directory and re install the pod through "pod install".

Answer 40

On the new Mac OS to solve the problem you should run using rosetta on Xcode

go to:

Xcode -> Product -> Destination -> Destination Architectures -> Show Both

Now you will have a rosetta simulator for all of your simulators

Run your code with one of the rosetta simulators and you are good to go

Answer 41

In my case: Xcode 12

I set empty values on EXCLUDED_ARCHS and set ONLY_ACTIVE_ARCH Debug = YES Release = NO Project's Build Setting

And I included this in my Podfile:

post_install do |installer|
    installer.pods_project.targets.each do |target|
        target.build_configurations.each do |config|
            config.build_settings["EXCLUDED_ARCHS[sdk=iphonesimulator*]"] = "arm64"
        end
    end
end

It runs on my Simulator iPhone 8 (iOS 12) and iPhone 11 Pro Max (iOS 14) and on my device iPhone 7 Plus (iOS 13.4).

Answer 42

On Build Settings search VALID_ARCH then press delete. This should work for me with Xcode 12.0.1

Answer 43

It worked for me when I set $(ARCHS_STANDARD) for VALID_ARCHS for Debug for Any iOS Simulator SDK. Also I have set YES for ONLY_ACTIVE_ARCH for Debug.

Answer 44

In the below image, in Excluded Architectures → in debug and release tap + button → in both debug and release.

Answer 45

Adding this to the end of my pod file fixed the error:

post_install do |installer|
  installer.pods_project.targets.each do |target|
    target.build_configurations.each do |config|
      config.build_settings["EXCLUDED_ARCHS[sdk=iphonesimulator*]"] = "arm64 i386"
    end
  end
end

Answer 46

See this tech note: https://developer.apple.com/documentation/technotes/tn3117-resolving-build-errors-for-apple-silicon Excluding the arm64 for the simulator should be a temporary solution.

Answer 47

In my case:

I had four configurations (+ DebugQa and ReleaseQa). Cocoapods is used as a dependency Manager.

For DebugQa, I gathered on the device and in the simulator, and on ReleaseQa only on the device.

It helped to set BuildActiveArchitecture to "yes" in PodsProject.

Answer 48

In my case, I was trying to run on an watchOS 7 simulator in Release mode, but the iOS 14 simulator was in Debug mode.

So simply putting both simulators in Debug/Release mode solved the problem for me!

Answer 49

Set the "Build Active Architecture Only"(ONLY_ACTIVE_ARCH) build setting to yes, xcode is asking for arm64 because of Silicon MAC architecture which is arm64.

arm64 has been added as simulator arch in Xcode12 to support Silicon MAC.

/Applications/Xcode.app/Contents/Developer/Platforms/iPhoneSimulator.platform/Developer/SDKs/iPhoneSimulator.sdk/SDKSettings.json

Answer 50

Switch Build Configuration back to Debug mode or turn on Build Active Architecture Only for both Debug and Release mode.

The reason is your library/framework doesn't support new simulator architecture ARM64 (run on Mac with an Apple silicon processor).

Answer 51

Add line "arm64" (without quotes) to path: Xcode* → Project → Build settings → Architectures → Excluded architectures.

Also, do the same for Pods. In both cases, for both debug and release fields.

Or in detail...

Errors mentioned here while deploying to simulator using Xcode 12 are also one of the things which have affected me. Just right-clicking on each of my projects and showing in finder, opening the .xcodeproj in Atom, then going through the .pbxproj and removing all of the VALIDARCHS settings. This was is what got it working for me.

I tried a few of the other suggestions (excluding arm64, Build Active Architecture Only) which seemed to get my build further, but ultimately leave me at another error. Having VALIDARCH settings lying around is probably the best thing to check for first.

Answer 52

Only add Any iOS Simulator SDK → x86_64 to Project's Build Settings → VALID_ARCHS works for me.

Xcode version: 12.1 (12A7403)

If your project includes some frameworks that don't support x86_64.

• You can add these framework names(xxx.framework) to Target → Build Settings → Excluded Source File Names → Debug → Any iOS Simulator SDK.
• And then modify the Framework Search Paths to delete the paths of these frameworks for Debug → Any iOS Simulator SDK.

These two settings can avoid Xcode to build and link these frameworks in simulator mode.

Answer 53

I understand the issue with arm64 and Xcode 12 and I was able to resolve build issues by excluding the arm64 architecture for iPhone Simulator or by setting ONLY_ACTIVE_ARCH for Release scheme. However I still have problems to push my framework using pod repo push.

I found out that setting s.pod_target_xcconfig in my podspec does not apply this setting to dependencies defined in the same podspec. I can see it in the dummy App project that Cocoapods is generating during the validation. Cocoapods validation is running release scheme for simulator and this is failing when one or more dependencies doesn't exclude arm64 or is not set to build active architecture only.

A solution could be to force Cocoapods to add post install script while validating the project or let it build Debug scheme, because the Debug scheme is only building active architecture.

I ended up using Xcode 11 to release my pod to pass the validation. You can download Xcode 11 from developer.apple.com, copy it to Applications folder as Xcode11.app and switch using sudo xcode-select --switch /Applications/Xcode11.app/Contents/Developer. Don't forget to switch back when done.

Answer 54

After excluding arm64 I always got ARCHS[@]: unbound variable. For me the only solution was to add x86_64 to the target build setting as mentioned here Problems after upgrading to Xcode 12:ld: building for iOS Simulator, but linking in dylib built for iOS, architecture arm64 You also might remove the exclude arm64 you added before.

Answer 55

I had the same issue for the simulator/SwiftUI preview with the following warnings:

ld: warning: ignoring file Pods/.../X.xcframework/ios-arm64_armv7/X.xcframework/X, missing required architecture x86_64 in file Ignoring file Pods/.../X.xcframework/ios-arm64_armv7/X.xcframework/X (2 slices)

I had recursive path $(SRCROOT) in the Framework Search Path in my project settings. After removing it, the project built without the error.

Answer 56

In our case it was an error in a Jenkins build:

Frameworks/release' xxx/Library/Developer/Xcode/DerivedData/xxx-cuytrcyjdlfetmavpdonsknoypgk/Build/Products/Debug-iphoneos/AppsFlyerLib.framework/AppsFlyerLib(AFSDKDevice.o), building for iOS, but linking in object file built for Mac Catalyst, file 'xxx/Library/Developer/Xcode/DerivedData/xxx-cuytrcyjdlfetmavpdonsknoypgk/Build/Products/Debug-iphoneos/AppsFlyerLib.framework/AppsFlyerLib' for architecture arm64

We fixed it with sudo gem update cocoapods.

Answer 57

I got the same error after switching to Macbook Pro M1 App Silicon. Solution that worked for me:

• delete the Podfile.lock
• run pod install that's it.

Answer 58

I didn't need to build for a simulator.

The cause for me was that I had selected an iPad under iOS Simulators in the top bar where you choose the build target - selecting a real device or just Any iOS Device (arm64, armv7) fixed the issue.

Answer 59

Here's the only thing that worked for me:

Add this to debug (non-release) builds:

// Speed up non-production builds by building only for the currently selected architecture
ONLY_ACTIVE_ARCH = YES

// For unknown reasons we need this to be able to compile for simulators in Apple Silicon macOS without Rosetta
VALID_ARCHS = arm64 armv7 arm64-ios-simulator

And remove all instances of customization of the EXCLUDED_ARCHS setting for all configs (debug and release), including the infamous EXCLUDED_ARCHS[sdk=iphonesimulator*] = arm64 one.

These were the tests I ran after making those changes, and everything passed, on native Apple Silicon (Xcode without Rosetta mode):

	Debug	Staging	Release
Build & Run on Device	✅	✅	✅
Build & Run on Simulator	✅	✅	✅
Archive	✅	✅	✅
Validated against App Store Connect	N/A	N/A	✅

Answer 60

I've seen quite a bit of weird behavior with frameworks, I think due to changes to the simulators to support Apple silicon. My temporary workaround is, in my app/extension targets, to add "arm64" to the Excluded Architectures build setting when building for the simulator (as your preview appears to be trying to do), and setting "Build Active Architecture Only" to No for all schemes. Might be worth a try.

Answer 61

I faced the same issue I just set Enable Bitcode to No.

Answer 62

I had similar problem but then I just put these lines of codes into Podfile at the bottom:

post_install do |installer|
  installer.pods_project.targets.each do |target|
    flutter_additional_ios_build_settings(target)
    target.build_configurations.each do |config|
      config.build_settings.delete 'IPHONEOS_DEPLOYMENT_TARGET'
      config.build_settings['EXCLUDED_ARCHS[sdk=iphonesimulator*]'] = 'i386 arm64'
    end
  end
end

Works like a charm! Do not forget to upvote my answer if it helps you. Thank you great developer :)

Answer 63

When I encounter this error, I use a 2 years ago c static lib with Xcode 14. When I achieve with the choose "Any iOS Device(64)" and connect a iPhone 14, this error pop up. But when I connect iPhone 12, this error gone.

The root cause is the c static lib is too old and can't support iPhone 14, even it supports arm64 and you can use lipo to check which architecture a lib supported.

After I ask lib provider to download the newest Xcode and build a new release, this issue has been resolved.

Answer 64

For me non of the solutions worked...

I use Xcode 14

What worked was - deintegrating Cocopods, cleaning the cache, and installing it again

In the project directory run

1. pod deintegrate ProjectName.xcodeproj
2. then run pod cache clean --all
3. then pod install

After cleaning and building again it worked

Answer 65

In my case it's working 100%. Try this:

I have a temporary solution.

You just follow the image.

• Double click architecture and select Other and Remove all lines

• Add two things arm7s and arm7

• Run your physical device on the iPhone, not the simulator

• Enjoy...
